S90 – NewNote Solutions

Operating System

Android 14

Memory

2GB RAM, 32GB FLASH
4GB RAM, 64GB FLASH (optional)
MicroSD card slot up to 512 GB

Customer Display

2.5-inch, with touchscreen functionality (optional)

Positioning

AGPS / GPS / GLONASS / BEIDOU / GALILEO

Smart Card Reader

EMV L1/L2, conforming to ISO 7816, 1.8V/3V/ 5V, synchronous & asynchronous, T=0 & T=1

Camera

2 MP front camera, support 1D/2D code payment
5 MP autofocus rear camera with flashlight, support 1D/2D code payment
13 MP autofocus rear camera with flashlight, support 1D/2D code payment (optional)
Professional code scanner, hardware decoding , support 1D & 2D code payment (optional)

Keypad

1 x power button, 1 x VOL+,1 x VOL-, 1 x function button

Peripheral Ports

1 x Type C port, 6 POGO PIN

Sensor

Vibration Motor / G-Sensor / Light-Sensor

Power Supply

Input: 100-240V AC 50/60Hz
Output: 5.0V DC, 2.0A

Weight

386g including battery

Certifications

EMV L1, EMV CL1, PCI 7.x, EMV L2, PayPass, PayWave, ROHS, TQM, AMEX, D-PAS, CE, FCC, JCB, UnionPay QuickPass, ATEX

Operating System	Android 14
Processor	AP:Cortex Octa-core (4xA73 + 4xA53), Maximum 2.0 GHz SP: Cortex-M3 security core, 192MHz
Memory	2GB RAM, 32GB FLASH 4GB RAM, 64GB FLASH (optional) MicroSD card slot up to 512 GB
Display	6.75-inch TFT full color LCD display, resolution of 720 x 1600, with adjustable backlight, capacitive multi-touch screen, support electronic signature
Customer Display	2.5-inch, with touchscreen functionality (optional)
Wireless Communication	4G / 3G / 2G Wi-Fi (802.11 a/b/g/n/ac) 2.4G&5G, Bluetooth 5.0
Positioning	AGPS / GPS / GLONASS / BEIDOU / GALILEO
Magnetic Card Reader	Triple track, bi-directional, conforming to ISO 7810/7811/7813
Smart Card Reader	EMV L1/L2, conforming to ISO 7816, 1.8V/3V/ 5V, synchronous & asynchronous, T=0 & T=1
Contactless Card Reader	EMV Contactless L1, conforming to ISO 14443 Type A/B, Mifare , Felica, HCE
Camera	2 MP front camera, support 1D/2D code payment 5 MP autofocus rear camera with flashlight, support 1D/2D code payment 13 MP autofocus rear camera with flashlight, support 1D/2D code payment (optional) Professional code scanner, hardware decoding , support 1D & 2D code payment (optional)
Audio	1 x Speaker ,1 x Microphones 1 x Speaker ,2 x Microphones (optional)
Keypad	1 x power button, 1 x VOL+,1 x VOL-, 1 x function button
Printer	High-speed thermal printer, 80mm/s Paper roll diameter: 40mm Paper width: 58mm
Peripheral Ports	1 x Type C port, 6 POGO PIN
Card Slots	1 Nano SIM +1 Mini SIM +1 PSAM + 1 SD 1 Nano SIM + 2 PSAM + 1 SD (optional) 1 Nano SIM + 2 PSAM + 1 SD + 1 eSIM (optional)
Sensor	Vibration Motor / G-Sensor / Light-Sensor
Battery	Polymer Battery: 7.6/2600mAh 19.76Wh Polymer Battery: 7.6/3500mAh 26.6Wh (optional)
Power Supply	Input: 100-240V AC 50/60Hz Output: 5.0V DC, 2.0A
Dimensions	190mm (L) x 80.5mm(W) x 50mm(H) (Minimum hight: 20mm)
Weight	386g including battery
Environment	Operating temperature: -10℃～50℃ (14℉~122℉) Storage temperature: -20℃～60℃ (-4℉~140℉) Relative humidity: 5%～95% (Non-condensing)
Certifications	EMV L1, EMV CL1, PCI 7.x, EMV L2, PayPass, PayWave, ROHS, TQM, AMEX, D-PAS, CE, FCC, JCB, UnionPay QuickPass, ATEX
